Currency Discrimination Fitness Sorter SB - 2000 Service Manual
39
In order that a system
analyzes Reference Level
and a signal of the machine,
the system should know the
full swing of a waveform of a
signal.
What is shading?
Shading is to make a full swing reference waveform to read the full level of a signal. If the
machine rejects too many notes in Mixed Mode or in CF Detection Mode, the system
might not analyze the input of waveform. It is possible to make a standard waveform for
the system. For more detail information, please refer to the Chapter 9.
1. UV SET
2. MR SET
3. IR SET
4. MODE SET
5. FIT PASS SET
When the machine ask the password: Press ‘35719’
8-1-5. SHADING
8-1-6. CF & MODE SET
UV, MR, and IR SET: If you want to select some specified sensor performance, you can do that in
this mode.
