Currency Discrimination Fitness Sorter SB - 2000 Service Manual
43
4) SENSOR LOGIC TEST
In this mode, you can check whether the sensor is defective or not by checking the logic status
of each sensors.
Below picture shows logic status.
When the sensors are covered by note, the status will ‘L(Low)’
Sensors
Not Covered Covered
Left Right Left Right
RP1 H H L L
RP2 H H L L
JP H H L L
SP H H L L
COVER
L (Front door is
closed)
L (Rear door
is closed)
H(Front door
is Open)
H (Rear door
is Open)
ST & RE
H(No notes in
Stacker)
H(No notes in
Rejecter)
L(Note in
Stacker)
L(Note in
Rejecter)
5) UV TEST
This Test Mode is only for developer.
6) MR TEST
This Test Mode is only for developer.
7) SOIL SENSOR TEST
This Test Mode is only for developer.
