Currency Discrimination Fitness Sorter SB - 2000 Service Manual
45
8-2-4. MOTOR TEST
Motor Test
In this test mode, you can run the main motor in various speeds. And also you can check the
condition of the exit motor that turns the wheel.
8-2-5. SELECTOR TEST
4. MOTOR TEST
1. MAIN 800 RPM ON
2. MAIN 1000 RPM ON
3. MAIN 1200 RPM ON
4. MAIN MOTOR STOP
5. EXIT MOTOR ON
▼ 6. EXIT MOTOR OFF
4. MOTOR TEST
▲ 2. MAIN 1000 RPM ON
3. MAIN 1200 RPM ON
4. MAIN MOTOR STOP
5. EXIT MOTOR ON
6. EXIT MOTOR OFF
7. MAIN LOW RPM ON
MENU
MODE
CODE : 55757
DISPLAY
4
MENU
MODE
CODE : 55757
DISPLAY
5
