SBM SB-2000 - IR Shading Procedure

Currency Discrimination Fitness Sorter SB - 2000 Service Manual
52
IMAGE SHADING
WAIT . . ABOUT 5 SEC
WARNING
FOR PROPER SHADING
REFER TO THE SVC
MANUAL
PRESS ESC TO CANCEL
PRESS ENTER TO GO
IMAGE SHADING
MIN
MAX
AVG
UNI
B
0.00
0.03
0.00
―
W
0.66
1.14
0.97
81%
OnTime 1 : R= 88 / G = 134 / B= 76
OnTime 2 : R= 46 / G = 68 / B= 41
OnTime : IR_R = 0
OK
5. SHADING
1. CIS
2. IR
3. SOIL
4. UV
5. MR
6. CAP
Check if CIS SHADING result is
“OK” In case Uniformity value is
under 70%, the result is “NG”
After the SHADING, open rear
cover and take out the SHADING
SHEET.
Processing...
Select the 1. CIS.
In displaying this message, press
‘START’ key.
