Currency Discrimination Fitness Sorter SB - 2000 Service Manual
7
(O)
Correct way to lift the
machine
Setting Up Your Machine
Power Cord
Plug one end of the cord into the back of the machine and the other end into a standard AC power
outlet.
If you turn on the power switch, the machine will display initializing process. If there is Service Call
number saved by a service provider, the Call number will be displayed as below:
And the machine will display version of software and its checksum also.
Printer
Your SB-2000 has a serial interface port, which allows you to connect your printer to print out
counting result. To connect your printer to the machine, follow the steps below:
1. Make sure that both the SB-2000 and the printer are turned off.
2. Plug the cable of printer into the serial port of SB-2000.
3. Turn the SB-2000 on and set parameters referring to the “Ch 8. Set Function and its
Parameters -> Interface”
To Next Page
