Starting and driving
OPM 100 en-GB 36
© Scania CV AB 2023, Sweden
Reaction to fault in the exhaust gas after-
treatment system – EU Stage V/China IV
The symbol and behaviour of the warning lamp
depend on the installation of the engine in the
machine. The Scania recommendation will lead
to the behaviour and symbol described here, but
this may differ between different machines.
Once the fault has been remedied and the engine
management system has received an indication
that the exhaust gas aftertreatment system is op-
erational, i.e. when the fault code has been ac-
knowledged in SDP3, torque returns to the
normal level.
Warning
lamp
Torque and speed control
Constant
light
None
Flashes
slowly
(½ Hz)
Torque is reduced by 1% per minute
to 75 % of the highest torque.
Flashes rap-
idly (2 Hz)
Torque is reduced by 1% per minute
to 50% of the highest torque. The
engine speed is reduced to 60% of
the nominal engine speed.
Symbol for faults in the exhaust gas aftertreatment
system.
