10 Technical data Failsafe brake
Operating Manual 90° ACTUSAFE CMF(S)QT
OM-ENGLISH-Failsafe-QT-16xx-V2.00-2022.03.01
10 Technical data Failsafe brake
10.0.1 CM03F(S)QT
Power: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16W
Voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 V
Current: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0,67 A
10.0.2 CM06F(S)QT
Power: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21W
Voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 V
Current: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0,875 A
10.0.3 CM12F(S)QT
Power: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28W
Voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 V
Current: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,17 A
11 Spare parts
When ordering spare parts, let us know the serial number of the actuator.
A separate exploded diagram and a spare parts list is available for selecting spare parts.
12 Lubricant recommendation / Lubricant requirements
See operating manual ACTUSMART CM.V1.2, section 15, page 76
12.1 Lubricant points F(S)QT
The table values given apply to relubrication in accordance with the relubrication intervals in the operating instructions.
After relubrication has been carried out, 2-3 full strokes must be performed. If torque switch off occur, the grease nipples
must be removed and the strokes repeated.
NOTE: Lubricant can leak out of the lubrication points.
The grease nipples should be reinstalled, in case of removal.
The spindle nut is or should be lubricated during initial assembly or after complete disassembly, including all gears and
bearings. Also, all moving parts as well as internal surfaces are coated to cover them.
→ Lubricant quantity according to expenditure
→ Lubricant specification according to the operating instructions depending on the temperature range
Type
Lubrication point [Quantity]
1 2 3
Main gear
Bearing spindle
drive
Intermediate gear
[cm
3
] [cm
3
] [cm
3
]
CM03F(S)QT30 8 - -
CM03F(S)QT60 18 - -
CM06F(S)QT100 20 42 -
CM06F(S)QT200 20 68 29
CM06F(S)QT300 20 90 59
CM06F(S)QT500 20 80 90
20
