Schiedel CM03 - Mode of operation CM03 + QT

Operating Manual 90° ACTUSAFE CMF(S)QT
OM-ENGLISH-Failsafe-QT-16xx-V2.00-2022.03.01 20 Technical data
20.8 Mode of operation CM03 + QT
ON-OFF & INCHING operation
CM03 + QT12 CM03 + QT25 CM06 + QT50
S2 - 15 minutes according to IEC
60034
S2 - 15 minutes according to IEC
60034
S2 - 15 minutes according to IEC
60034
2,5 - 10 RPM 2,5 - 20 RPM 2,5 - 20 RPM
M
max
= 120 Nm M
max
= 250 Nm M
max
= 500 Nm
M
avg
= 60 Nm M
avg
= 125 Nm M
avg
= 160 Nm
Life time
*
10.000 cycles 10.000 cycles 10.000 cycles
MODULATING operation
CM03 + QT12 CM03 + QT25 CM06 + QT50
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
2,5 - 10 RPM 2,5 - 20 RPM 2,5 - 20 RPM
M
max
= 120 Nm M
max
= 250 Nm M
max
= 500 Nm
M
avg
= 60 Nm M
avg
= 125 Nm M
avg
= 250 Nm
Life time
*
1.800.000 starts 1.200.000 starts 1.200.000 starts
CONTINUOUS MODULATING operation
CM03 FS 30/5 CM03 FS 50/8 CM03 FS 100/12
S9 - 1.800 c/h according to IEC
60034
S9 - 1.800 c/h according to IEC
60034
S9 - 1.800 c/h according to IEC
60034
2,5 - 10 RPM 2,5 - 20 RPM 2,5 - 20 RPM
M
max
= 120 Nm M
max
= 250 Nm M
max
= 500 Nm
M
avg
= 40 Nm M
avg
= 80 Nm M
avg
= 160 Nm
Life time
*
1.800.000 starts 1.200.000 starts 1.200.000 starts
*
NOTE: life time is based on proper operation and maintenance according to SCHIEBEL operating manual
CYCLE = movement of 90° in both directions with at least 30% of nominal toque and the ability to accept 100% of nominal
torque for at least 5% of the stroke
START = movement of at least 1° of stroke in both directions with a load of minimum 30% of nominal torque
