7 Parameter menu
Operating Manual 90° ACTUSAFE CMF(S)QT
OM-ENGLISH-Failsafe-QT-16xx-V2.00-2022.03.01
7.19 Default User Level Settings
The following table shows the default user level settings for all parameters on a brand-new actuator.
Parameter Menu item Sub-menu item
Default UL
Read
Default UL
Write
P1.1 End Limit Open 1 3
P1.2 End Limit Close 1 3
P1.3 End Limit Switch Off Open 2 4
P1.4 End Limit Switch Off Close 2 4
P1.5 End Limit Closing direction 2 4
P1.7 End Limit LED Function 1 3
P1.8 End Limit Hysteresis 2 4
P1.9 End Limit Ramp 2 4
P1.10 End Limit Range 2 4
P1.11 End Limit Overrun Open 2 4
P1.12 End Limit Overrun Close 2 4
P2.1 Torque Open 2 4
P2.2 Torque Close 2 4
P4.1 Speed Local Open 2 4
P4.2 Speed Local Close 2 4
P4.3 Speed Remote Open 2 4
P4.4 Speed Remote Close 2 4
P4.5 Speed Emerg. Open 2 4
P4.6 Speed Emerg. Close 2 4
P4.7 Speed Torquedep. oper. 2 4
P4.8 Speed Minimal 2 4
P5.1 Ramp Local 2 4
P5.2 Ramp Remote 2 4
P5.3 Ramp Emergency 2 4
P6.2 Control Ready delay 2 4
P6.5 Control 24V Output 2 4
P6.6 Control Min. Impuls 2 4
P6.17 Control Remote Display 2 4
P7.1 User Level Local 2 4
P7.2 User Level Bus 2 4
P7.3 User Level Remote Display 2 4
P7.4 User Level Change Password 1 1
P8.1 Position Intermed.pos.1 1 3
P8.2 Position Intermed.pos.2 1 3
P8.3 Position Intermed.pos.3 1 3
P8.4 Position Intermed.pos.4 1 3
P8.5 Position Emerg.position 1 3
P8.6 Position Hysteresis 1 3
P8.7 Position Intermed.pos.5 1 3
P8.8 Position Intermed.pos.6 1 3
P8.9 Position Intermed.pos.7 1 3
P8.10 Position Intermed.pos.8 1 3
P8.11 Position Dead Band 1 3
P8.12 Position Gain 1 3
P8.13 Position Hysteresis 1 3
P8.14 Position Intermed.pos.9 1 3
P8.15 Position Intermed.pos.10 1 3
P8.16 Position Intermed.pos.11 1 3
continued on next page
