Operating Manual 90° ACTUSAFE CMF(S)QT
OM-ENGLISH-Failsafe-QT-16xx-V2.00-2022.03.01 7 Parameter menu
continued from previous page
Menu item Sub-menu item poss. setting Notes / comments
4: Service +
Restores all parameters to the service backup
parametrization, including the end limits (P1.1 and P1.2)
and the switch off torques and torque limit(P2.1, P2.2
and P2.3).
5: Workshop -
Restores all parameters to the workshop backup
parametrization, without changing the end limits (P1.1
and P1.2) and the switch off torques and torque
limit(P2.1, P2.2 and P2.3).
6: Workshop +
Restores all parameters to the workshop backup
parametrization, including the end limits (P1.1 and P1.2)
and the switch off torques and torque limit(P2.1, P2.2
and P2.3).
P20.4 Miscellaneous Save Backup
0: no action
1: Customer
By saving this setting, the current parameters are
adopted as customer parameters.
2: Service
By saving this setting, the current parameters are
adopted as service parameters.
3: Workshop
By saving this setting, the current parameters are
adopted as workshop parameters.
P20.5 Miscellaneous Info line 0. . . 15
The bottom line of the display shows various diagnostic
values.
P20.6 Miscellaneous Wireless
0: Off The infrared and bluetooth connection is disabled.
1: Infrared
The infrared connection is active for about 3 minutes
unless communication is detected.
2: Bluetooth
The Bluetooth connection is active for about 3 minutes
unless communication is detected.
3: Infrared+ The infrared connection is activated.
4: Bluetooth+ The Bluetooth connection is activated.
P20.7 Miscellaneous Menu style 0. . . 2 different menu styles
P20.9 Miscellaneous Time
Sets the date and time on the actuator. Move the red
selector switch to highlight the next value, and down to
highlight the prior value.
P20.10 Miscellaneous Timezone -840. . . 840 min. Sets the timezone; offsets the shown time in minutes.
P20.11 Miscellaneous
Daylight saving
time
0: Off Time without daylight saving
1: On Turns on daylight saving time
2: Auto
With this setting, the daylight saving time is automatically
detected.
NOTE: Backups are prioritized; the higher the number, the higher the priority. For example, if parameters are backed up as
service, the customer parameters will be overwritten.
