20.10 Mode of operation CM03 + LK
ON-OFF & INCHING operation
CM03 + LK50 CM03+ LK100 CM03 + LK120
S2 - 15 minutes according to IEC
60034
S2 - 15 minutes according to IEC
60034
S2 - 15 minutes according to IEC
60034
2,5 - 72 RPM 2,5 - 72 RPM 2,5 - 60 RPM
F
max
= 15 kN F
max
= 30 kN F
max
= 60 kN
F
avg
= 15 kN F
avg
= 15 kN F
avg
= 20 kN
Life time
*
10.000 cycles 10.000 cycles 10.000 cycles
MODULATING operation
CM03 + LK50 CM03+ LK100 CM03 + LK120
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
S4 - 1.200 c/h - max. 50% DC
according to IEC 60034
2,5 - 36 RPM 2,5 - 36 RPM 2,5 - 30 RPM
F
max
= 15 kN F
max
= 30 kN F
max
= 60 kN
F
avg
= 15 kN F
avg
= 15 kN F
avg
= 30 kN
Life time
*
1.800.000 starts 1.200.000 starts 1.200.000 starts
CONTINUOUS MODULATING operation
CM03 + LK50 CM03+ LK100 CM03 + LK120
S9 - 1.800 c/h according to IEC
60034
S9 - 1.800 c/h according to IEC
60034
S9 - 1.800 c/h according to IEC
60034
2,5 - 20 RPM 2,5 - 20 RPM 2,5 - 20 RPM
F
max
= 15 kN F
max
= 30 kN F
max
= 60 kN
F
avg
= 10 kN F
avg
= 10 kN F
avg
= 20 kN
Life time
*
1.800.000 starts 1.200.000 starts 1.200.000 starts
*
NOTE: life time is based on proper operation and maintenance according to SCHIEBEL operating manual
CYCLE = stroke of 40 mm in both directions with at least 30% of nominal toque and the ability to accept 100% of nominal
torque for at least 5% of the stroke
START = movement of at least 1% of stroke in both directions with a load of minimum 30% of nominal torque
20.11 Miscellaneous
Ambient temperature:
non explosion-proof version: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -25 . . . +60°C
explosion-proof version: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-20 . . . +40°C (according EN 60079-0)
ex version with extended temperature range: . . . . . . . . . . . . . . . . . . . . . . . -40 . . . +60°C
Protection according to EN 60529: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IP67
Standard colour: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RAL7024
NOTE: If the actuator is exposed to excessive UV-light, colour deviations of the painting might occur.
