14 Mode of operation F(S)QT
Operating Manual 90° ACTUSAFE CMF(S)QT
OM-ENGLISH-Failsafe-QT-16xx-V2.00-2022.03.01
14 Mode of operation F(S)QT
14.1 CM03 F(S)QT
ON-OFF & INCHING operation
CM03 F(S)QT 30 CM06 F(S)QT 60
S2 - 15 minutes according to IEC 60034 S2 - 15 minutes according to IEC 60034
2,5 - 72 RPM 2,5 - 72 RPM
M
max
= 300 Nm M
max
= 600 Nm
M
avg
= 150 Nm M
avg
= 300 Nm
Life time
*
10.000 cycles 10.000 cycles
MODULATING operation
CM03 F(S)QT 30 CM06 F(S)QT 60
S4 - 1.200 c/h - max. 50% DC according to IEC
60034
S4 - 1.200 c/h - max. 50% DC according to IEC
60034
2,5 - 36 RPM 2,5 - 36 RPM
M
max
= 300 Nm M
max
= 600 Nm
M
avg
= 150 Nm M
avg
= 300 Nm
Life time
*
1.200.000 starts 1.200.000 starts
CONTINIOUS MODULATING operation
CM03 F(S)QT 30 CM06 F(S)QT 60
S9 - 1.800 c/h according to IEC 60034 S9 - 1.800 c/h according to IEC 60034
2,5 - 20 RPM 2,5 - 20 RPM
M
max
= 300 Nm M
max
= 600 Nm
M
avg
= 100 Nm M
avg
= 200 Nm
Life time
*
1.200.000 starts 1.200.000 starts
NOTE: Life time is based on proper operation and maintenance according to SCHIEBEL operating manual
CYCLE = movement of 90° in both directions with at least 30% of nominal force and the ability to accept 100% of nominal
torque for at least 5% of the stroke
START = movement of at least 1° of stroke in both directions with a load of minimum 30% of nominal torque
