7 Parameter menu
Operating Manual 90° ACTUSAFE CMF(S)QT
OM-ENGLISH-Failsafe-QT-16xx-V2.00-2022.03.01
continued from previous page
Menu item Sub-menu item poss. setting Notes / comments
33: Intermediate
position3
As intermediate position 1, but with higher priority than
intermediate position 4
34: Intermediate
position4
As intermediate position 1, but with lowest priority.
35: Emergency
position
Approach emergency position (P 8.5). As intermediate
position 1, but with higher priority than intermediate
positions 1, 2
36: Intermediate
position1 inv.
As Intermediate position 1, but active low
37: Intermediate
position2 inv.
As Intermediate position 2, but active low
38: Intermediate
position3 inv.
As Intermediate position 3, but active low
39: Intermediate
position4 inv.
As Intermediate position 4, but active low
40: Emergency
position inv.
As Emergency position, but active low
41: Travel Open reserved for future use
42: Travel Close reserved for future use
43: Travel Open
inv.
reserved for future use
44: Travel Close
inv.
reserved for future use
45: Failsafe lock reserved for future use (only for Failsafe actuators)
46: Failsafe lock
inv.
reserved for future use (only for Failsafe actuators)
47:
Intermed.pos.Bit0
Intermed.pos.Bit0 to Intermed.pos.Bit3 allow to signal
intermediate positions 1 to 16 through a bit pattern
(binary to decimal; decimal value + 1 corresponds to the
Int.pos.). Bit3 is the MSB. E.g. to move to Int.pos.1, all
Bits should be 0; to move to Int.pos.3, Bit 1 should be 1.
48:
Intermed.pos.Bit1
see 47: Intermed.pos.Bit0
49:
Intermed.pos.Bit2
see 47: Intermed.pos.Bit0
50:
Intermed.pos.Bit0
inv.
As 47: Intermed.pos.Bit0 but active low
51:
Intermed.pos.Bit1
inv.
see 50: Intermed.pos.Bit0 inv.
52:
Intermed.pos.Bit2
inv.
see 50: Intermed.pos.Bit0 inv.
53: PVST Start Start PVST (optional, see PVST section)
54: PVST Start inv. As 53: PVST Start, but active low.
55:
Intermed.pos.Bit3
see 47: Intermed.pos.Bit0
56:
Intermed.pos.Bit3
inv.
see 50: Intermed.pos.Bit0 inv.
P9.2 Bin. Input Input 2 see Input 1
P9.3 Bin. Input Input 3 see Input 1
P9.4 Bin. Input Input 4 see Input 1
P9.5 Bin. Input Input 5 see Input 1
NOTE: For optional functions such as a relay board or virtual inputs please refer to the corresponding IOM.
