11.1 The WEXK Audio/Visual Indicators
Action LED Indications
WEXK
Sounder
1
WEXK is powered and then displays
software version number
X red flashes then Y green flashes
*
none
2a WEXK Relocks (motor runs) 1 red flash 1 beep
2b
If linking, WEXK sends a link
request (up to 3 times per RF
channel) looking for a WPIM in link
mode
1 green flash;
then 1 red flash
once for each link request sent
none
2c
If linking, WEXK & WPIM do an
Packet-Error-Rate test for about 20
seconds
flashes for each RF transmission:
green flash for a good transmission
red flash for a bad transmission
none
2d
If linking, WEXK linked successfully
and indicates the RF Channel on
which it linked
Z green flashes
**
Z beeps
*
2e
Or if linking, WEXK not linked
successfully
2 red flashes 1 long beep
3
Card swiped and not read, if iCLASS
reader see section 13.5
none none
4
Card swiped and read, if iCLASS
reader see section 13.5
none 1 beep
5
No RF communications with card
swipe
1 red flash – immediate none
6 Access denied
2 red flashes – delayed about 1-15
seconds
1 beep
7
Access granted, WEXK unlocks
(motor runs)
1 green flash none
8 WEXK Relocks (motor runs) 1 red flash 1 beep
*
X = major software version number (any number is possible)
*
Y = minor software version number (any number is possible)
**
Z = RF channel number that the WEXK linked on (1-15)
Table 11-1 – WEXK Indicators
11.2 Linking the WEXK to a WPIM
NOTE: Only one WEXK can be linked at a time.
11.2.1 If the WEXK does not have a Battery Pack installed, install one now (section 5.4).
11.2.2 Make certain that the WPIM to be linked to is in the Link Mode (Section 2.3.2).
11.2.3 To initiate the linking process:
11.2.3.1 Open the door.
11.2.3.2 Hold the crash bar down to create a Request to Exit condition.
11.2.3.3 While holding the crash bar down to activate the Request to Exit switch, read a card to the card
reader (refer to section 5.3).
11.2.3.4 Continue to hold down the crash bar (Request to Exit) until the WEXK LED’s start to blink
indicating that the link process has begun (approximately 8 seconds), then release the lever.
11.2.3.5 Close the door.
