Overview
The Schlage optional remote antenna module is an external antenna that provides a
means of increasing the radio frequency (RF) range between a Panel Interface Module
(PIM) and a Wireless Access Point Module (WAPM). WAPM’s include AD-400 locks,
Wireless Reader Interfaces (WRI400), Wireless Status Monitors (WSM400) and Wireless
Portable Readers (WPR400).
The remote antenna module is connected to the remote antenna connector on a PIM400 or
WRI400.
• Before installing a remote antenna module, read the user guide for the PIM400 or
WRI400 and the WAPM.
• As with all radio systems, interference may be a problem. Some causes of interference
are microwave ovens, certain lighting systems, microwave transmitters, or high speed
processors for computers.
Getting started
Follow these general steps when setting up a remote antenna module:
1. Install the PIM400 or the WRI400 in a designated location within 15 cable feet of where
the remote antenna will be located. (For more information on the PIM400 or WRI400,
see the installation guides that came with the products, or visit www.schlage.com/
support.)
2. Remove power from the PIM400 or WRI400.
3. Thoroughly check all national and local electrical codes regarding grounding and
lightning protection.
4. Familiarize yourself with the information contained in this user guide.
Save this user guide for future reference.
