3 • Schlage • PIM400-1501 user guide
Overview
The Schlage PIM400-1501 combines the Schlage PIM400-485 and EP-1501 Access
Platform into a single product.
The Schlage PIM400-1501-LC provides the Schlage PIM400-485 in an enclosure designed
to receive an EP-1501 board.
L Please refer to the PIM400-1501-LC instructions for futher information on
completing the installation of the EP-1501 board (see instruction sheet number
P516-781). Once the EP-1501 board is installed, the PIM400-1501-LC operates as
the PIM400-1501 as described in this guide.
L For UL installations, the PIM400-1501-LC must be used with an EP-1501 board
that is UL294 listed.
The PIM400-1501 communicates over ethernet to host software, and by wireless
transmission with up to 16 AD-Series Wireless Access Point Modules (WAPMs). WAPMs
compatible with the PIM400-1501 include the Schlage AD-400 locks, WRI400 and WPR400.
This manual describes the operation and installation of the Schlage PIM400-1501.
• The PIM400-1501 is wired to an ethernet network connection.
• The PIM400-1501 is powered externally one of two ways, selected by the power
selector jumper, J3:
a. Power over ethernet (PoE), Class 3, fully compliant to IEEE 802.3af, or
b. 12 VDC power supply connected to TB4-3 (VIN) and TB4-4 (GND). The 12 VDC
power supply must be compatible with all components and must have the
capacity to power the PIM400-1501 and any other devices attached to the same
supply. (The PIM400-1501 requires a power supply capable of sourcing at least 400
mA @ 12 VDC).
For UL installations, PoE powered devices shall not be used.
Power for these devices must be provided by a UL-294 listed, ULC-S318 Listed or
ULC-S319 Listed power limited power supply capable of sourcing at least 400mA at
12 VDC.
Use of the Model CENB1010A1265C02 with the PIM400-1501 is permitted for UL-
294 Listed applications only.
• Ideal installation location is determined by the location of the WAPM(s).
• The PIM400-1501 communicates to the WAPM(s) using Radio Frequency (RF).
• The WAPM is installed at the access point where access will be controlled and/or
monitored.
• The PIM400-1501 is suitable for indoor use, ambient temperature range 0°C to +66°C
(+32°F to +151°F).
• SRAM is protected against power outage by a rechargeable battery.
• Please refer to the Access Control Panel manufacturer’s instructions and documentation
for information on operation of the ACP.
• Please refer to Mercury documentation for the latest updates and information on the
Mercury product.
