Schmid Watson - Power Consumption; Plug-In; Tabletop; Ethernet

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
11-2
Revision: 2010-01-20
Data Rate:
9600 Baud, Asynchronous
Protocol:
8 Bit, No Parity, 1 Stop Bit
No Linefeed with Carriage Return
XON/XOFF enabled
Connector Type:
SubD9 female
11.2 Power Consumption
11.2.1 Plug-in
Supply Voltage:
-40.5V
DC
.. -72V
DC
Power Consumption:
9 W max
11.2.2 Tabletop
Local Power Supply
Remote Power Supply
Supply Voltage
-40.5V
DC
.. -72V
DC
-112V
DC
.. -65V
DC
at tabletop
DSL-Connector
Power Consumption
SZ.847.V350
2.1 W max
SZ.847.V450
3.1 W max
11.3 Ethernet
Plug-in
Tabletop
Maximum Frame Size
1'536 bytes
2’048 bytes
Number of MAC ad-
dresses
1'024
1’024
Number of address data-
bases
15
1
Number of VLANs
64
VLAN transparent
Frame buffer size
120 Kbytes shared be-
tween all queues
56 Kbytes shared between all
queues
Rate limiters
Configurable (128/256/512
Kbps and 1/2/4/8 Mbps)
Configurable (CIR=1 bit/s to
100 Mbps, CBS=0 to 64
Kbytes)
Number of Queues
4 per port
4 per port
CoS Classifiers
Layer 2 Priority
Layer 3 DSCP
Layer 2 Priority
Layer 3 DSCP
