Schmid Watson User Manual

Watson-Ethernet-Manual.doc
Version 3.3-01
Watson Ethernet
Operating Manual
Revision: 2010-01-20
7-27
7.3 Fault and Maintenance Management FMM
7.3.1 Diagnostic
DIAGNOSTIC
The DIAGNOSTIC (or DIA) command shows the current DSL status. It is
available from all menus by typing DIA.
LTU_01_FMM> DIA
-----------------------------------------+---------------
Diagnostic: SQ Attn PWR Status | Alarms
-----------------------------------------+---------------
DSL span 1 |
STU-C A: 18 0 +13.5 Sync | LKINT
STU-R A: 14 0 +13.5 Sync | LKINT
-----------------------------------------+---------------
DSL span 2 |
STU-C A: 0 0 +13.5 Handshake | LOSW,LKINT
STU-R A: -- -- -- Idle | ---
-----------------------------------------+---------------
DSL span 3 |
STU-C A: 0 0 +13.5 Handshake | LOSW,LKINT
STU-R A: -- -- -- Idle | ---
-----------------------------------------+---------------
DSL span 4 |
STU-C A: 0 0 +13.5 Handshake | LOSW,LKINT
STU-R A: -- -- -- Idle | ---
-----------------------------------------+---------------
On the tabletop the DIA display looks different:
NTU_CM> DIA
---------------------------------------------+--------------------
Diagnostic: SQ G.826(ES) Attn Status | Alarms
---------------------------------------------+--------------------
NTU-A: +25.0 00000001 +00.00 Sync | LOS-S
NTU-B: +25.0 00000001 +00.00 Sync |
---------------------------------------------+--------------------
NTU_CM>
After DIA the screen is continuously updated until the next Monitor command is
entered.
SQ
Signal Quality
G.826(ES)
G.826 errored seconds (only available on the Watson Ethernet
tabletop)
Attn
Link attenuation
PWR
Transmit power (only available on the Watson Ethernet plug-in)
Status
Synchronization status
Alarms
List of all active alarms
