Table 3-4 shows of all possible rate combinations (k  kbit/s, M  MBit/s):
Pro-
file
Q1
Q2
Q3
Q4
Pro-
file
Q1
Q2
Q3
Q4
1
128k
128k
128k
128k
2
128k
128k
128k
256k
3
256k
256k
256k
256k
4
256k
256k
256k
512k
5
512k
512k
512k
512k
6
512k
512k
512k
1M
7
1M
1M
1M
1M
8
1M
1M
1M
2M
9
2M
2M
2M
2M
10
2M
2M
2M
4M
11
4M
4M
4M
4M
12
4M
4M
4M
8M
13
8M
8M
8M
8M
14
8M
8M
8M
16M
15
128k
256k
256k
256k
16
128k
256k
256k
512k
17
256k
512k
512k
512k
18
256k
512k
512k
1M
19
512k
1M
1M
1M
20
512k
1M
1M
2M
21
1M
2M
2M
2M
22
1M
2M
2M
4M
23
2M
4M
4M
4M
24
2M
4M
4M
8M
25
4M
8M
8M
8M
26
4M
8M
8M
16M
27
8M
16M
16M
16M
28
8M
16M
16M
32M
29
128k
128k
256k
256k
30
128k
128k
256k
512k
31
256k
256k
512k
512k
32
256k
256k
512k
1M
33
512k
512k
1M
1M
34
512k
512k
1M
2M
35
1M
1M
2M
2M
36
1M
1M
2M
4M
37
2M
2M
4M
4M
38
2M
2M
4M
8M
39
4M
4M
8M
8M
40
4M
4M
8M
16M
41
8M
8M
16M
16M
42
8M
8M
16M
32M
43
128k
256k
512k
512k
44
128k
256k
512k
1M
45
256k
512k
1M
1M
46
256k
512k
1M
2M
47
512k
1M
2M
2M
48
512k
1M
2M
4M
49
1M
2M
4M
4M
50
1M
2M
4M
8M
51
2M
4M
8M
8M
52
2M
4M
8M
16M
53
4M
8M
16M
16M
54
4M
8M
16M
32M
55
8M
16M
32M
32M
56
8M
16M
32M
64M
Table 3-4: Ingress rate limiter profiles
Each combination of rates is associated with a profile number. This profile num-
ber is used in the RATELIMIT IN Monitor command to configure a particular
combination of rates.
Note that the ingress rate limits are overlap and non-cumulative. The aggregate
bandwidth of Q1 .. Q4 is limited by the maximum bandwidth of Q4. Figure 3-13
shows the bandwidth allocation for ingress profile 50:
