6.3 Naming of ports
Many commands of the Monitor relate to a particular port. These ports are identi-
fied as follows:
Port
Name
Bridge port of 1
st
DSL span
DSL1
Bridge port of 2
nd
DSL span
DSL2
Bridge port of 3
rd
DSL span
DSL3
Bridge port of 4
th
DSL span
DSL4
1
st
Ethernet user interface
ETH1
2
nd
Ethernet user interface
ETH2
3
rd
Ethernet user interface
ETH3
4
th
Ethernet user interface
ETH4
1
st
Management Ethernet interface (Q)
MGMT1
2
nd
Management Interface (Backplane)
MGMT2
3
rd
Management Interface (Bridge)
MGMT3
Table 6-1: Port naming
Cf. also Figure 3-4.
The number of DSL spans varies depending on the card configuration set by the
CARDMODE command, cf. Table 3-1.
6.4 Telnet Access
To use a remote Monitor through Telnet on the Watson Ethernet plug-in you first
have to configure the IP address of the plug-in through a monitor on the RS-232
interface with the MGMTIP command.
Then use any Telnet client to open a telnet session into the modem. You will see
a Telnet welcome screen:
+-----------------------------------------------+
| Welcome to Watson Ethernet Quad LTU |
| (C) by Schmid Telecom AG Zuerich, Switzerland |
+-----------------------------------------------+
OS/HW: Linux ppc 2.4.20
Nodename: SzW5EthLtu
SzW5EthLtu login:
Enter username and password to display the Monitor Welcome Screen.
Note:
The default username is root, the default password is sz . It is not possible to
change these.
