DEFAULT Configuration
The DEFAULT command sets a default configuration. The following default set-
tings are available on the plug-in:
Parameter
DEFAULT 0
DEFAULT 1
DEFAULT 2
SHDSL
Master/Slave
Master
Master
Master
Autorestart
Enabled
Enabled
Enabled
Power
Backoff
Enabled
Enabled
Enabled
Linerate per
span
8'192 kbit/s
4'096 kbit/s
2'048 kbit/s
Operating
Mode
1 x 4 Pair
2 x 2 Pair
4 x 1 Pair
DSL Sync
rate per pair
2'056 kbit/s
2'056 kbit/s
2'056 kbit/s
Ethernet
Interface
mode
Auto
Auto
Auto
Flow control
Auto
Auto
Auto
VLAN Set-
tings
Bridgemode
1 (VLAN Bridging)
VLANs
VLAN 1: ETH1,
DSL1
VLAN 1: ETH1,
DSL1
VLAN 3: ETH3,
DSL3
VLAN 1: ETH1, DSL1
VLAN 2: ETH2, DSL2
VLAN 3: ETH3, DSL3
VLAN 4: ETH4, DSL4
VLAN 4094: MGMT3
All ports are configured as untagged
CoS Settings
Default
Priority
Q1 on all ports
Priority
source
IEEETHENIP on all ports
Priority map-
ping
L2 Priority: 0 1 2 3 4 5 6 7
Queue : Q2 Q1 Q1 Q2 Q3 Q3 Q4 Q4
Table 7-2: DEFAULT values (plug-in)
