Schmid Watson User Manual

Watson Ethernet
Operating Manual
Watson-Ethernet-Manual.doc
Version 3.3-01
7-28
Revision: 2010-01-20
Note
A DSL master displays information both for the local and remote ends (STU-C
and STU-R on the Watson Ethernet plug-in, LTU and NTU sides on the Watson
Ethernet tabletop). DSL slaves display only local information.
7.3.2 Status (Plug-in)
STATUS
STATUS displays information about the status of the DSL spans.
LTU_01_CM> STATUS
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
SHDSL STATUS
Span : 1 | 3 |
Name : UBS01 | ETHZ |
Pair : A B | A B |
Wire Pair : a1a2 b1b2 | c1c2 d1d2 |
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Admin. Status : up | up |
Master/Slave : Master | Master |
Line Rate : 2056 kb/s | 0 kb/s |
Payload Rate : 4096 kb/s | 0 kb/s |
Transmission Mode: ANNEX_B | -- |
PID : 1 | 2 | 1 | 2 |
Attributes:
Master/Slave
DSL Master or slave status
ActualPaylRate
Currently configured linerate
MaxAttnPaylRate
The maximum possible linerate
TransmissionMode
Current transmission mode (always ANNEX_B)
PID
Pair identification
