5 LEDs and Alarms
5.1 Plug-in LEDs
The plug-in is equipped with four LEDs. Depending on the currently selected
CARDMODE the LEDs are mapped to local and remote status as follows:
Cardmode
1 (4 x 1p)
2 (2 x 2p)
3 (1 x 2 + 2x1p)
4 (1 x 4p)
LED
Span
Function
Span
Function
Span
Function
Span
Function
A
DSL1
Local Sta-
tus
DSL1
Local Sta-
tus
DSL1
Local Sta-
tus
DSL1
Local Sta-
tus
B
DSL 2
Local Sta-
tus
DSL1
Remote
Status
DSL1
Remote
Status
DSL1
Remote
Status
C
DSL 3
Local Sta-
tus
DSL3
Local Sta-
tus
DSL3
Local Sta-
tus
-
Off
D
DSL 4
Local Sta-
tus
DSL3
Remote
Status
DSL4
Local Sta-
tus
-
Off
Table 5-1: LED mapping for plug-in
The "Local Status" LED indicates the status of the local end of the DSL span
(STU-C side). The Remote Status" LED indicates the status of the remote end of
the DSL span (STU-R side). If the modem is configured as DSL slave then only
the local status is indicated, the "Remote Status" LED is switched off.
5.1.1 Plug-in LED Indications
Status
LED
Power failure
Off
Hardware / Software failure
blinking red
Normal operation (Master)
Green
Normal operation (Slave)
Green
Non-urgent alarms (local/remote) or loop active
Amber
Urgent alarms (local/remote)
Red
Table 5-2: Plug-in LED indications
