11.7 Environment
11.7.1 Climatic Conditions (Plug-in and Tabletop)
Storage:
ETS 300 019-1-1 Class 1.2
-25 C … +55 C, 10% .. 100% RH
Transportation:
ETS 300 019-1-2 Class 2.3
-40 C … +70 C, max. 95% RH
Operation:
ETS 300 019-1-3 Class 3.2e
-5 C … +60 C, 5% .. 95% RH
11.7.2 Safety
According to EN 60950:2006 (IEC60950:2005)
11.7.3 EMC
According to EN 300386:2000
11.8 Physical dimensions and weight
11.8.1 Plug-in
19” Plug-in unit: height: 259mm (6 HE), width: 30mm
PCB dimensions: height: 233.35mm, length: 220mm
Weight 500g
11.8.2 Tabletop
Tabletop unit: width 220mm, depth 195mm, height 43mm
Weight 750g
