HDLCTAG ON | OFF
ON Ethernet frames are transmitted over the DSL span with Cisco HDLC fram-
ing
OFF Ethernet frames are transmitted with compressed HDLC framing. This set-
ting must be used if the Watson Ethernet tabletop is connected to the Wat-
son Ethernet plug-in.
Cf. chapter 3.2
7.2.6 Ethernet Bridging Configuration (Plug-in)
AGING [ Time ]
Defines the aging time for all entries in the address learning database of the
Ethernet bridge.
Parameter:
Time
Aging time in seconds: 16 .. 4'000
AGING without parameters will display the current aging time.
BRIDGEMODE [ Mode ]
Sets the Ethernet bridge mode. Cf. 3.2.2
Parameter:
1
VLAN bridging: bridging is based on 802.1Q based VLAN tags
2
Transparent bridging (port-based)
3
Transparent bridging with inband management cf. 3.5.5
BRIDGEMODE without parameter will display the currently active Bridgemode.
CONFIG ETHERNET Ethernet-Port
Shows the current configuration of an Ethernet port:
LTU_01_CM> CONFIG ETHERNET ETH1
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Local Configuration of Bridges Ethernet Port ETH1
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
AutoNegFDX : auto
FlowControl : off
Doubletagging : off
DefaultVlanId : 1
DefaultPrio : Q1
VlanList : egress tagged : -
egress untagged : 1
Loop : Off
PrioSrc : IEEETHENIP
FLT [ ON | OFF ]
Bridge filtering mode (global for the entire bridge):
ON MAC address filtering enabled. Only broadcast packets and packets with
destination addresses known to be on the Ethernet segment of a port will
be forwarded to this port. Address filtering is VLAN aware.
