Schmid Watson - Ethernet Bridging Configuration (Tabletop); VLAN Configuration (Plug-In)

Watson-Ethernet-Manual.doc
Version 3.3-01
Watson Ethernet
Operating Manual
Revision: 2010-01-20
7-11
OFF MAC address filtering disabled. All Ethernet packets are transferred trans-
parently to all Ethernet interfaces.
Typing FLT without argument displays the current configuration
7.2.7 Ethernet Bridging Configuration (Tabletop)
AGING [ Time ]
Defines the aging time for all entries in the address learning database of the
Ethernet bridge.
Parameter:
Time
Aging time in seconds: 0 .. 3825
AGING without parameters will display the current aging time.
FLT [ ON | OFF ]
Bridge filtering mode (global for the entire bridge):
ON MAC address filtering enabled. Only broadcast packets and packets with
destination addresses known to be on the Ethernet segment of a port will
be forwarded to this port. Address filtering is VLAN aware.
OFF MAC address filtering disabled. All Ethernet packets are transferred trans-
parently to all Ethernet interfaces.
Typing FLT without argument displays the current configuration
7.2.8 VLAN Configuration (Plug-in)
CONFIG VLAN
VLAN without parameters displays the current VLAN configuration:
LTU_01_CM> CONFIG VLAN
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
VLAN-Id FID ETH DSL MGMT Name
1* 2* 3* 4* 1* 2* 3* 4* 3*
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
1 1 U - - - T - - - - VLAN-1
2 2 - U - - - T - - - VLAN-2
3 3 - - U - - - T - - VLAN-3
4 4 - - - U - - - T - VLAN-4
4094 16 - - - - - - - - U VLAN-4094
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Ports: ETH1 ETH2 ETH3 ETH4 DSL1 DSL2 DSL3 DSL4 MGMT3
Default Vlan: 1 2 3 4 1 2 3 4 4094
Default Prio: Q1 Q1 Q1 Q1 Q1 Q1 Q1 Q1 Q4
Doubletagging: off off off off off off off off
Bridgemode: 2 (Transparent VLAN)
VLAN-ID
VLAN Id
FID
Forwarding database used for this VLAN
