7.3.3 Status (Tabletop)
The status of the tabletop is available with the following command
STATUS
NTU_FMM> STATUS
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Local System Status V5.0
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
SYNC-A: 02 OPS-A: 01 PID-A: 01 PWR-A: +13.50 UPS: 01
SYNC-B: 02 OPS-B: 01 PID-B: 02 PWR-B: +13.50
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
NTU_FMM>
SYNC
00
01
02
03
04
05
06
07
Status of SHDSL synchronization state machine accord-
ing to TS 101 524.
Out of Sync State
State 0
In Sync State
State 1
State 2
State 3
State 4
State 5
OPS
00
01
10
18
80
Operational mode of the transceiver
Idle Mode
Data Mode
Startup handshake in progress
Startup training in progress
Local analog loopback
PWR
n
Transmit power of each channel [dBm]
