Technical data
01.00 | CMS | Assembly and operating manual | en | 1553577 15
3 Technical data
Designation CMS
040 050 063 080 100 125
Pitch diameter [mm] 40 50 63 80 100 125
CMS-K Weight [kg] 0.16 0.27 0.49 0.75 1.52 3.09
CMS-K-B Weight [kg] 0.16 0.27 0.49 0.77 1.52 3.18
CMS-AWeight [kg] 0.09 0.14 0.27 0.43 1.04 1.72
CMS-A-N Weight [kg] 0.09 0.14 0.27 0.42 1.03 1.7
CMS-A-B Weight [kg] 0.09 0.15 0.3 0.47 1.11 1.85
Repeatability [mm] <0.02 <0.02 <0.02 <0.02 <0.02 <0.02
Max. dynamic torsional moment [Nm] 15 27 48 75 230 465
Max. dynamic bending moment [Nm] 22.5 35 75 115 230 478
Max. dynamic tensile force [N] 350 450 500 800 1200 1500
Pneumatic feed-through (max. 8 bar) 4 x M5 6 x M5 6 x
G1/8"
9 x
G1/8"
12 x
G1/8"
12 x
G1/4"
Permitted loading assuming the following conditions
More technical data is included in the catalog data sheet.
Whichever is the latest version.
