Operation
01.00 | CMS | Assembly and operating manual | en | 1553577 23
NOTE
Grease the lock bolt if it does not move freely
1. Secure the CMS-A against falling down.
2. Pull the suspended bolt on the hand lever.
3. Turn the hand lever 180° until it stops (unlock).
ð CMS-K and CMS-A can be pulled apart in the axial
direction.
6.2 Locking
CAUTION
Danger of crushing due to moving parts.
Fingers and hands can be crushed when locking the manual
change system.
l
Proceed with caution when locking.
l
Do not place fingers between the hand lever, manual change
head and manual change adapter.
1. Move the hand lever into the open position.
2. CMS-K and CMS-A one inside the other in this position.
3. Close the hand lever and snap in the suspended bolt into the
bore hole.
ð Lock is in effect.
