SCHUNK CMS 050 - Page 26

Maintenance
26 01.00 | CMS | Assembly and operating manual | en | 1553577
Item Designation CMS
040 050 063 080 100 125
4 Designation Seal kit Seal kit Seal kit Seal kit Seal kit Seal kit
ID 1551974 1551976 1551979 1552000 1552001 1552003
Amount in
Seal kit
4 6 6 9 12 12
5 Designation Hand lever
with
detent pin
Hand lever
with
detent pin
Hand lever
with
detent pin
Hand lever
with
detent pin
Hand lever
with
detent pin
Hand lever
with
detent pin
ID 1548020 1548021 1548023 1548025 1548028 1548041
6 Designation Bolt lug Bolt lug Bolt lug Bolt lug Bolt lug Bolt lug
ID 1544222 1544223 1544223 1544224 1544225 1544228
