SCHUNK OSE - 3 Technical Data

Technical data
3 Technical data
Designation OSE
Pressure medium Compressed air, compressed air
quality according to
ISO 8573-1:7 4 4
Nominal working pressure [bar] 6
Min. pressure [bar] 4.5
Max. pressure [bar] 8
Ambient conditions and operating conditions
Designation OSE
Ambient temperature [°C]
min.
max.
+5
+60
Protection class IP * 54
Noise emission [dB(A)] ≤ 70
* For use in dirty ambient conditions (e.g. sprayed water, vapors,
abrasion or processing dust) SCHUNK offers corresponding
product options as standard. SCHUNK also offers customized
solutions for special applications in dirty ambient conditions.
More technical data is included in the catalog data sheet.
Whichever is the latest version.
1703.00 | OSE | Assembly and Operating Manual | en | 1373804
