Maintenance
38 03.00 | OSE | Assembly and Operating Manual | en | 1373804
Assembly of the
pistons
1. Install the 1st piston (4) as shown in the Figure.
2. Turn the 1st piston (4) 180° and remove the pin (8).
✓ Piston 1 (4) now is used as fixing pin.
3. Install the 2nd piston
4. Turn the first piston by 180° and remove the pin. (7).
5.4 Disassemble product
Position of the item numbers, }5.6 [
/
41].
5.4.1 OSE 14
Disassemble 1. Remove air connections.
2. Remove covers (3, 4).
3. Mark positions of pinion (14/15) and the piston (2). For versions
with air passage, mark also the rotary transmission leadthrough
(17).
4. Remove circlip (85).
NOTE
Only versions with integrated air passage: first remove rotary
transmission leadthrough (17), then circlip.
5. Draw pinion (14/15) out of housing.
6. Push piston (2) out of housing.
7. Remove all seals.
Remove
absorbing spring.
1. Remove cover (3).
2. Remove set screw (33).
Assembly is done in reverse order with set screw (33) being flush
screwed in to the back of piston.
5.4.2 OSE 22 - 45
Disassemble 1. Remove air connections.
2. Remove covers (3, 4).
3. Mark positions of pinion (14/15) and the piston (2). For versions
with air passage, mark also the rotary transmission leadthrough
(17).
4. Remove circlip (85).
NOTE
Only versions with integrated air passage: first remove rotary
transmission leadthrough (17), then circlip.
5. Draw pinion (14/15) out of housing.
6. Push piston (2) out of housing.
7. Remove all seals.
