Operation Manual - SP 305
Figure 37
Accumulator charge kit for HYDAC
bladder accumulators
Nitrogen bottle
Hose
30341207
Charge valve assembly
30341201
Tan k
pressure
Regulated
pressure
High pressure gas
regulator is not
included with the
kit. These are
available from the
nitrogen supplier.
Regulator adjustment
handle
HYDAC bladder
accumulator
BPL
Accumulator Charging Kit
(Includes hose and charge valve assembly)
SCHWING PART NUMBER:
30338635
200
1
50
100
5
00
1000
1
5
00
2000
2
5
00
50
0
bar
PSI
