4
2010.10 / i
LeRoY-SoMeR
ALTERNATEURS
Valeurs excit / Excit. values
en charge / full load
à vide / at no load
Tension
Voltage
Secours
Std by
40C
27C
PUISSANCE / RATING
Connex.
kVA
kW
A
kVA
kW
A
V
Ph.
Continue
Continuous
LSA Date
N° Hz
Min
-1
/R.P.M. Protection
Cos Ø /P.F. Cl. ther. / Th. class
Régulateur/A.V.R.
Altit. m Masse / Weight
Rlt AV/D.E bearing
Rlt AR/N.D.E bearing
Graisse / Grease
ALTERNATORS
1 - RECEIPT
1.1 - Standards and safety measures
Our alternators comply with most international standards.
See the EC Declaration of Incorporation on the last page.
1.2 - Inspection
On receipt of your alternator, check that it has not suffered any
damage in transit. If there are obvious signs of knocks, contact the
transporter (you may able to claim on their insurance) and after a
visual check, turn the machine by hand to detect any
malfunction.
1.3 - Identiîš¿cation
The alternator is identiîš¿ed by means of a nameplate glued to
the frame.
Make sure that the nameplate on the alternator conforms to
your order.
The alternator name is deîš¿ned according to various criteria
(see below).
Example of description: LSA 43.2 M45 J6/4
• LSA: Name used in the PARTNER range
• M: Marine
• C: Cogeneration
• T: Telecommunications
• 43.2: Machine type
• M45: Model
• J: Excitation system (C: AREP/J: SHUNT or PMG/
E: COMPOUND)
• 6/4: Winding number/number of poles
1.3.1 - Nameplate
So that you can identify your alternator quickly and accurately,
we suggest you îš¿ll in its speciîš¿cations on the non-contractual
nameplate below.
1.4 - Storage
Prior to commissioning, machines should not be stored in
humid conditions: at relative humidity levels greater than 90%,
the machine insulation can drop very rapidly, to just above zero
at around 100%. The state of the anti-rust protection on
unpainted parts should be monitored.
For storage over an extended period, the alternator can be
placed in a sealed enclosure (heatshrunk plastic for example)
with dehydrating sachets inside, away from signiîš¿cant and
frequent variations in temperature to avoid the risk of
condensation during storage.
If the area is affected by vibration, try to reduce the effect of
these vibrations by placing the generator on a damper support
(rubber disc or similar) and turn the rotor a fraction of a turn
once a fortnight to avoid marking the bearing rings.
1.5 - Applications
These alternators are designed mainly to produce electricity in
the context of applications involving the use of generators.
1.6 - Contra-indications to use
Use of the alternator is restricted to operating conditions
(environment, speed, voltage, power, etc.) compatible with the
characteristics indicated on your genset.
INSTALLATION AND MAINTENANCE
LSA 43.2 / 44.2 - 4-poLe
ALTeRNAToRS
3434 en -
