STEP 3
(from STEP 2) When the leaf reaches the closing mechanical stop, press button P1 (Fig. 6).
Motor M1 will also start a closing cycle.
When the gate reaches the closing mechanical stop, press P1 again (Fig. 7). Do not execute this operation if limit
switches are installed.
Note: If the safety gate is installed you must give the impulse exactly on the stop.
3
The leaf stops and M1 starts an opening cycle.
After a few seconds press P1 once more to set the Leaf Delay in Opening. (The number of seconds waited will result in the
delay of the leaf in opening) NOT TO DO IF DIP 4 IN “ON” POSITION.
When the leaf reaches the opening mechanical stop, press P1 again (Fig. 8). Do not execute this operation if limit switches
are installed. Motor M2 will also start an opening cycle. When it reaches the opening mechanical stop, press P1 again (Fig.
9). Do not execute this operation if limit switches are installed.
Press and Hold button P1 (LED P will come ON)
until motor M2 will start to close the gate*.
Release P1.
P1
LEDP
P1
M2M1
P1
If the motor start to open the gate, take OFF the power and reverse the motor phases.
Make the same type of connection on motor M1 as well.
Repeat the programming procedures (STEP 2).
*
Fig. 6
P1 P1
M2M1
Fig. 7
M2M1
Fig. 8
P1 P1
M2M1
Fig. 9
M2M1
GATE 2
SELF-LEARNING OF OPERATING TIMES
FOR SWING GATES OPERATORS
