Output 1 activates instantly (the door is released instantly) when the Egress Button is pressed.
1 – 99 --- E gress Delay Timing
Put any number of 1 to 99 into the box to enable the Egress Delay. The number is the time in second, which starts to count when the
Egress Button is pressed. Output 1 activates (the door is released) when the delay time reaches.
NOTE:
1) Momentary Contact -- The Egress Delay starts to count when the egress button is momentarily pressed. Output 1activates
automatically (door is released) when the delay time reaches.
2) Holding Contact -- The user MUST hold the egress button in contact for the whole period of the Egress Delay time until Output 1
activates. If the egress button is released before the end of the Egress Delay, the timer will stop to count and reset.
3) The Egress Delay does not affect the operation of the User PINs for Output 1. The User PINs always give INSTANT action.
Example: (Please see the following page)
EXAMPLES:
Example 1: Set Egress Button in Momentary contact 5 seconds with delay & warning beep
90 2 5 #
(a) (b) ( c) (d)
(a) Egress function programming, (b) Momentary contact with warning,
(c) Delay time of 5 seconds to release door, (d) Entry confirmation
Example 2: Set Egress Button in Holding contact of 10 seconds with warning beep
90 5 10 #
(a) (b) ( c) (d)
(a) Egress function programming, (b) Holding contact mode with warning,
(c) Holdin g time of 10 seconds to release door, (d) Entry confirmation
Example 3: Set Egress Button in Momentary contact without delay (This is the default setting)
90 1 0 #
(a) (b) ( c) (d)
(a) Egress function programming, (b) Momentary contact without delay,
(c) Release door instantly, (d) Entry confirmation
DOOR OPENING ALARM & TIMER (Location 91)
LOCATION ALARM TIME VALIDATION
91 0 or 1 - 999 #
ALARM & TIMING OF DOOR OPENING
0 --- No Alarm – (Default)
The Alarm Output is disabled
1 – 999 --- A larm Timer
The Door Open Alarm operates the Alarm Output (Terminal 13) only. It is mainly prepared to trigger an optional alarm system. Put
any Timing Figure of 1 to 999 into the box to enable the function of the Door Opening Alarm. The figure is the time in second of the
alarm duration, which starts to count after the door is opened and it resets automatically when the time reaches.
The alarm can be stopped with the User Codes/Cards or the Super User PIN for Output 1 at any time before the end of the alarm
time.
NOTE: The Door Opening Alarm is designed to protect the emergency exit door from use by the un-authorized person.
The alarm occurs when the door is opened or forced to open. However, Alarm will not happen if the door is opened with a valid User
Code.
47Rev. 01 - 05/201167411245
