Sistemi Elettronici
di Apertura Porte e Cancelli
International registered trademark n. 804888
®
PUSH
English
INTRODUCTION
FEATURES
SPECIFICATIONS
The keypad unit comes with plenty of functions for owner’s selection via programming. Owners can take them freely to tailor the
desired features for their system. It is an ideal keypad mainly for Door Strike and Alarm Arm-disarm control. It is also a
programmable industrial timer (with the timing of 1 second to over 24 hours) for Automatic Operator Systems.
PUSH – Output Relays for Output 1, 2 and 3 (Surface Mount Version)
• Indoor or outdoor installation
• Stand Alone or Inter-lock system built-in with all the required control logics
• Controls “Going in” with User PIN and “Going out” with programmable egress button
• Durable Steel housing for surface or gooseneck mounting (code: 12710208)
• Built-in Tamper Switch
• Heavy duty 1.5mm stainless steel faceplate
• Die-casting metal back-lit keyboard with dual brightness levels
• Vandal resistant and weatherproof (IP-66)
• Three outputs controlled by independent groups of codes / PINs
• Programmable Timers for Door Strike, Alarm Arm-disarm Control or Industrial Automatic Operators.
Operating Voltage: 12V-24V DC, Auto adjusting
Operating Current: 40mA (quiescent) to 100mA (three relays active)
Operation Temperature: -20 C to +70 C
Environmental Humidity: 5-95% relative humidity non-condensing
Working Environment & Ingress Protection: All weather, IP-66
Number of Users: Output 1 – 1,000 User PINs + 50 Duress Codes
Output 2 – 100 User PINs + 10 Duress Codes
Output 3 – 100U ser PINs + 10 Duress Codes
Number of Visitor Codes: 50, programmable for one time or with the time limit
Timings for Code Entry: 10 seconds waiting for next digit entry
The Timers: Three 1-99,999 Seconds (Over 24 Hours possible) Independent Programmable Timers
for O/P 1, 2 & 3
Egress Button: Programmable for Instant, Delay with Warning and/or Alarm
Momentary or Holding Contact for the Exit Delay
Input Sensing Terminals: a) Door position, b) Egress, c) O/P 1 inhibit
Output Control Terminals : Transistor Open Collector 24VDC/100mA sink Max for the following
outputs a) Duress, b) Alarm, c) Key Active,
d) Output 3 (Door Bell version only), e) Inter-lock
Output Contact Ratings: Output Relay 1 – N.C. & N.O. dry contacts, 5A/24VDC Max.
Output Relay 2 – N.C. & N.O. dry contacts, 1A/24VDC Max.
Output Relay 3 – N.C. & N.O. dry contacts, 1A/24VDC Max. (N.O. contact only for Door
Bell version)
Tamper Switch – N.C. dry contact, 50mA/24VDC Max.
Dimensions: PUSH – 125(H) X 79(W) X 46/54(D)mm
Weight: PUSH – 550g net
Housing: PUSH - Cast Aluminum, Power paint coating
Faceplate Material: 1.5mm stainless steel
Specications are subject to change for modication without notice
30 Rev. 01 - 05/201167411245
