RECORD - DELETE USER PINS FOR OUTPUT 1 , 2 , & 3 ( Locations 10 , 20 & 30)
Total of 1,200 User PINs are available for the 3 user groups to control the 3 outputs.
1) 1,000 ---- for Output 1 (Group 1)
2) 100 ------ for Output 2 (Group 2)
3) 100 ------ for Output 3 (Group 3)
The Private User PINs in the 3 user groups MUST be unique. Repeated PINs will be rejected.
LOCATIONS RECORD/DELETE USER ID USER PIN VALIDATION
10 - 30 2 or 5 000 - 999 USER PIN #
USER GROUP LOCATIONS
10 – Group 1 --For User PINs Controlling Output 1
1,000 Users are allowed in group 1 for O/P 1
20 – Group 2 --For User PINs Controlling Output 2
100 Users are allowed in group 2 for O/P 2
30 – Group 3 -- For User PINs Controlling Output 3
100 Users are allowed in group 3 for O/P 3
SELECTION OF RECORD OR DELETE A PIN
• Number 2 represents recording of an User PIN.
• Number 5 is the authorization code for deleting of an PIN from its User ID.
2 = Record An User PIN
5= Delete an User PIN from the selected User ID number
0999 = Clear all the PINs from the selected Location. It takes few seconds to a minute to
complete depending on the Location selected and the data stored.Please see the
Programming example below for the details.
USER ID NUMBER
• A 3-digit ID is an identied number for each User PIN.
• Repeated ID number will be rejected by the system
a) ID Number 000 - 999 for 1,000 User PINs to operate Output 1
b) ID Number 001 - 100 for 100 User PINs to operate Output 2
c) ID Number 001 - 100 for 100 User PINs to operate Output 3
THE USER PINS
• The User PINs can be 4-8 digits. Key in the User PIN on each ID Number box, then confirm it with # key
EXAMPLES – PROGRAMMING AND OPERATION
1) Example 1 -- User PIN for Output 1 :
i) Programming :
10 2 001 2468 #
(a) (b) (c) (d) (e)
(a) The User PIN is programmed for Output 1
(b) Record an User PIN
(c) Take ID number 001 in Group 1 to store the User PIN, which is one of the IDs in 000-999
(d) Key in the User PIN "2468" into the storage location
(e) Press # to store the “User PIN” into memory, two-beep confirms a valid entry
ii) Operation : (while the system is back to operation mode)
2468 #
(a) (b)
(a) Key in the User PIN “2468”
(b) Conrm it with the # key. Output 1 activates
