Sistemi Elettronici
di Apertura Porte e Cancelli
International registered trademark n. 804888
®
PUSH
English
• 18 : INTER-LOCK O/P (Inter-lock Control Output)
An NPN transistor open collector output with the maximum power rating of 24VDC/100mA sink. It is OFF at normal condition and it
switches to (-) ground immediately for the first 5 seconds after keying in a valid User PIN to operate Output 1, then, it will keep tying
to (-) ground during the Door Position Sensor is open circuit due to door opening. Use this output point to make cross wire
connection with the other keypad’s “O/P 1 Inhibit” point in an Inter-lock system to prevent both doors can be opened at the same
time.
An Inter-lock System:
An inter-lock system is a two-door system that always allows only one of the doors to open during the operation. While one
of the doors is opened, the other door keeps close until the open door is re-closed. It prevents the unauthorized people
dashing into a protected area while the doors are in use. An inter-lock system needs two keypads and two door position
sensing switches for the two doors.
• 19 - 20 : TAMPER N.C. (Tamper Switch Normally Closed Contact)
A normally closed dry contact while the keypad is secured on its box. It is open while keypad is separated from the box. Connect
this N.C. terminal to the 24 hour protection zone of an alarm system if necessary.
The tamper switch in the versions A and B is activated by the fixing screw of the front plate; in the versions C and D it is activated by
a magnet equipped on the back of the plastic box.
THE ON - BOARD LED INDICATORS
• RED / GREEN (Right) --- It lights up in Green for Output 1 activation; and Red for Output 2 activation.
• AMBER (Centre) ---------It flashes on Standby. It shows the system status in synchronization with the beep tones.
The standby flashing can be set to OFF in programming. See Location 73 for the details.
• RED (Left) ----------------It lights up while one of the outputs is inhibited. It is also the Wiegand LED in reader mode
THE PACIFIER TONES & THE LED SIGNALS
The buzzer and the amber LED indicator give following tones and signals respectively for system status:
STATUS TONES * LED SIGNALS
1) On Programming Mode ---------------- ON
2) Successful Key Entry 1 Beep 1 Flash
3) Successful Code Entry 2 Beeps 2 Flashes
4) Unsuccessful Code Entry 5 Beeps 5 Flashes
5) Power Up Delay Continuous Beeps Continuous Flashes
6) Output Relay Activation ** 1 Second Long Beep
7) On Standby *** ---------------- 1 Flash in 1 Seconds Interval
8) System Refreshing ---------------- Fast Flashes for 2.5 Minutes
9) PIN Already Stored in System 1 Long Beep ----------------
NOTE:
* All Pacier Tones can be ON or OFF through the programming option at Location 71
* * The Output Relay Activation beep can be selected through the programming option at Location 72
* * * The Standby ashing can be ON or OFF through the programming option at Location 73.
THE JUMPER FOR BACK - LIT SELECTION
1) Full Back-lit --- The keypad gives dim backlit on standby. It turns to full backlit when a key button is pressed, then back to dim
backlit 10 seconds after the last key button is pressed.
2) Auto Back-lit --- The backlit is OFF on standby. It turns to full backlit when a key button is pressed, then back to OFF 10 seconds
after the last key button is pressed.
33Rev. 01 - 05/201167411245
