• 6 - 7 - 8 : OUTPUT 2 (Output Relay 2)
1 Amp relay dry contact controlled by the Group 2 User PINs for Output 2, it is an auxiliary output ideally for controlling security
system or automatic operator. Terminal 6 is Normally Closed (N.C.), terminal 8 is Normally Open (N.O.) and terminal 7 is the
common point of the two contacts. The relay is programmable for Start/Stop (toggle) mode or Momentary timing mode. See
programming Location 52 for the details.
• 9 : EG IN ( Egress Input)
A Normally Open (N.O.) input terminal referring to (-) ground. With the help of connecting a normally opened button to activate
Output 1 for door opening in the same manner of using the Group 1 User PINs. Egress button is usually put inside the house near
the door. More than one egress buttons can be connected in parallel to this terminal. Leave this terminal open if not used.
See Programming Locations 90 and 91 for more information about the Egress Button with other features.
• 10 - 11 - 12 : OUTPUT 3 (Output Relay 3)
1 Amp relay dry contact controlled by the Group 3 User PINs for Output 3, it is an auxiliary output ideally for controlling security
system or automatic operator. Terminal 10 is Normally Closed (N.C.), terminal 12 is Normally Open (N.O.) and terminal 11 is the
common point of the two contacts. The relay is programmable for Start/Stop (toggle) mode or Momentary timing mode. See
programming Location 53 for the details.
• 13 : “K” OR “A” O/P (Keypad Active Output or Alarm Output)
An NPN transistor open collector output with the maximum power rating of 24VDC/100mA sink. It is equivalent to an N.O.
(Normally Open) terminal referring to ground. It can be used to drive small power device, such as a relay or a low power control
point for other equipment. This output point is selectable to give Keypad Active Output or Alarm Output via the Selection of the “K
or A” jumper.
a) Keypad Active Output (“K”) --- It switches to ( -) ground for 10 seconds on each key touch. It can be used to turn on light,
CCTV camera, or buzzer to notify a guard. See Application Hints for more information.
b) Alarm Output (“A”) --- It switches to ( -) ground while Alarm occurs in order to trigger external alarm to give notication at
remote location.
• 14 : DU OUT (Duress Output)
An NPN transistor open collector output with the maximum power rating of 24VDC/100mA sink. It is equivalent to an N.O.
(Normally Open) terminal switching to (-) ground after the Duress Code is entered. Use it to trigger an alarm zone of a security
system, or turn on a buzzer to notify a guard.
• 15 : ( - ) GND (Common Ground)
A grounding point of the keypad that is common to terminal 2.
• 16 : DOOR SENS N.C. (Door Position Sensing Input -- Normally Close)
A Normally Closed (N.C.) sensing point referring to ( - ) ground, with the help of a normally closed magnetic contact monitors the
open or close status of the door. It initiates the following functions for the system. Connect it with jumper to (-) Ground if not used.
a) Door Auto Re-lock
The system immediately re-locks the door after it is re-closed before the end of the programmed time for output 1. It
prevents unwanted “tailgate” entry.
b) Door Forced Open Warning
The keypad generates “door forced open” warning and alarm instantly once the door is forced to open without a valid user
PIN or egress button. The warning lasts as long as the time programmed (1 - 999 sec). It can be stopped with an User PIN
for output 1 at anytime. See programming Location 80 for the details.
C) Door Propped-up Warning
The keypad generates propped-up warning beeps (does not activates alarm output) while the door is left open longer than
the allowable time programmed. The warning will last as long as the door is open until re-closed. See programming
Location 81 for the details.
d) Inter-lock Control
The inter-lock control output always goes to ( - ) while the door is open, which gives signal to disable the other keypad in
the inter-lock system. See the Inter-lock terminal description for more information.
e) Door Opening Alarm
Door Opening Alarm is designed for the emergency door only. It is always given when the door is opened unless a valid
user code or card is used prior to the door is opened. See programming Location 91 for the details.
• 17 : O/P 1 INHIBIT N.O. (Output 1 Inhibit Control Input – Normally Open)
A Normally Open (N.O.) sensing input point for controlling the Output 1, with this terminal connecting to ( - ) ground, the Egress
Button, the group of User PINs for Output 1 are all disabled. It is prepared mainly for the cross wire connection with the “Inter-lock
O/P” point on the other keypad in an Inter-lock system.
NOTE: The inhibit function does not govern the Duress Codes and the Super User Codes. They are always valid.
