Seaory S21 - Internal Printer Structures; Internal Components Overview

Seaory S21 Desktop Single-sided Card Printer
Excellent quality, Perfect service www.seaory.com 6 / 51
Main function description：
Bottom cover: Place to install Magnetic stripe card and chip card encoding module.
3.6 Internal structures
Main function description:
A Air fan: absorb and release the print head’s heat when it works.
B Print head: need regular cleaning.
C Ribbon cartridge: accessory to install ribbon.
D Ribbon pickup roller: recycle used ribbon.
E Cleaning roller: sticky card surface dust, improve the printing effect.
F Card thickness regulator: Manual adjust card’s thickness, support 0.3mm-1.0mm
thickness cards.
G Ribbon supply roller : unused ribbon ends.
Card printer bar code: Information needed when you need technical services from us.
A
B
C
D
E
F
G
