Seca 452 - Preparing the Measuring Station; Installing the Seca 452 Interface Module

Connecting and installing the seca 452 interface module • 63
English
17-10-01-266-002a/07-2018B
Preparing the measuring station 1. Switch the measuring station off.
2. Disconnect the power supply unit from the power supply socket.
CAUTION!
Risk of injury and damage to device
The device must be tilted. The large overall height of the device can
result in injuries and damage to the device.
► Ensure that there are no other persons in the immediate vicinity.
► Ensure that there are no objects in the immediate vicinity.
3. Slightly lift the measuring station and pull off the power cable.
Installing the seca 452 interface
module
1. Put a hex head socket screw into a sliding block and guide the sliding
block into the groove of the column.
2. Hold the sliding block in position as shown in the following figure.
3. Position the bracket on the sliding block.
max. 20 cm
min. 5 cm
