6.7 Retrofitting measuring stations 285/284, 287/286
You need the following parts from set no. 4520000009:
Depending on the desired installation and connection version, you may need
the following tools (not included in the scope of delivery):
➔ Preparing the measuring station
➔ Installing the seca 452 interface module
➔ Mounting the scanner bracket
➔ Connecting a seca 452 interface module
➔ Performing final work
Pos. Component Pcs.
a
seca 452 interface module 1
b Bracket 1
c Scanner bracket 1
d Connecting cable 1
e Hex head socket screw 4
f Sliding block 2
Pos. Component Size
1 Hex socket wrench 4.0
2 Ethernet cable n/a
a
b
c
d
e
f
1
2
