Section 7: Valve Maintenance
MAX Valve Repair and Replacement
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 39
We Engineer Solutions
6. Now, start all bolts into the tube, turning
them in about 1/8". This allows you to
locate the holes in the tube easier by lifting
the ring and seal to see the holes.
7. Tighten all bolts equally as they are going
into plastic. Do not over tighten as you
would in metal.
8. String the control line and, before unrolling the coil of cable,
pass it through the center of the IDS hub. Once all the cable is
outside the bucket with no slack, push it 6" back into the
bucket.
9. Reattach the control cable to the head as shown in
the picture using four tie wraps.
