Section 7: Valve Maintenance
MAX Valve Repair and Replacement
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 41
We Engineer Solutions
Installing the New Cable
1. Examine the new drive cable to determine the shorter end.
2. Insert the short end of the drive cable into
the cable retainer, then insert the long end
of the cable through the hole in the lift bar.
3. Secure the cable retainer to the lift bar.
4. Trim the short end of the drive cable and
insert the cable through the cable bushing.
