Section 7: Valve Maintenance
MAX Valve Repair and Replacement
2016 Bambi MAX Service Manual – Models 1518-3542 (Version E) 44
We Engineer Solutions
10. Turn on the power and open the valve to
its full open position. Install the cable
through the second cable anchor and,
then, pull the cable tight and secure with
cable anchor screws. Install a piece of 1/
8" x 1" heat shrink over the cable next to
the anchor. Cut off the excess cable as
close to cable anchor as possible.
11. Adjust valve to correct position (see
Section 4 for more information).
