Each project with the AHC controller should be based on calculations and
plans that are exclusively yours and in accordance with the applicable regula-
tions. Pictures and text in this instruction are only an example and the publish-
er shall not be held liable. The liability of the publisher for unprofessional, false
and incorrect information and the consequential damage shall be expressly
excluded. We reserve the right to technical errors and changes without any
prior notice.
The connection of controlling devices should be performed by an expert with an appro-
priate qualication or an authorised organisation. Before interfering with the wiring, make
sure the main switch is switched o. Follow the regulations for low-voltage installations IEC
60364 and VDE 0100, legal regulations for the prevention of accidents, statutory provisions
for the protection of the environment and other national regulations.
ELECTRICAL CONNECTION OF THE CONTROLLER
CONNECTION OF TEMPERATURE SENSORS
The controller allows the connection of temperature sensors Pt1000 (T1 to T4). Sensor
function depends on the hydraulic schematic and setup of S1.6 and S1.7 parameters.
