Advanced functionalities
• Createnew waypoint: Right-click anywherein the Map Area thatdoes not
contain a symbol to bring up the context menu, then select ‘Add waypoint
here’ to add a new waypoint.
• Context menu: Right-click on a waypoint to bring up the context menu.
You can then select the following options:
– Go to: Select while the drone is in flight to make this the current des-
tination waypoint.
– Auto-next: Toggle the Auto-next parameter of the waypoint.
– Reverse turn direction: Toggle the Turn direction parameter of the
waypoint.
– Change altitude: Set the transition behaviour of the drone when
flying towards the selected waypoint.
– Remove waypoint: Remove the selected waypoint.
Any modification will be sent directly to the drone to updateits onboard waypoint
list. If the message is not acknowledged by the drone (for example due to a tem-
porary loss of communication link), the waypoint will move back to its previous
position on the map to accurately reflect the current waypoint list status within
the drone’s autopilot.
Note: Modification of flight plan parameters can cause the drone to
react in unexpected ways. In particular, the drone may have trouble
following its flight path when the radius is set very low or if there
is high wind. We highly encourage you to test your entire flight plan
using the simulator to get familiar with the drone’s behaviours before
going out into the field.
4.2 Advanced polygonal mission area
The mission area defines the area of interest where the eBee will take photos. It
appears as a grey rectangle when you select the ‘Mission planning’ tab and to cal-
culatethe flight plan ofthe drone. For many cases the rectangular-shaped mission
60
