SERVOPRO NOx Analyzers Page
192
Starting Address Hi 00 Byte Count 04
Starting Address Lo 00 Register Value Hi (1) 52
Number of Registers Hi 00 Register Value Lo (1) 2C
Number of Registers Lo 02 Register Value Hi (0)
Register Value Lo (0)
44
9A
The contents of Register 0 are shown as the 4 byte values of 44 9A, 52 2C hex, or 1234.56789
decimal.
EXAMPLE: Request to read Register 40201
Request Response
Field Name (Hex) Field Name (Hex)
Function 03 Function 03
Starting Address Hi 9D Byte Count 04
Starting Address Lo 09 Register Value Hi (40202) 33
Number of Registers Hi 00 Register Value Lo (40201) 33
Number of Registers Lo 02 Register Value Hi (40201)
Register Value Lo (40201)
41
8F
The contents of register 40201 are shown as the four byte values of 41 8F 33 33 hex, or 17.9
decimal.
EXAMPLE: Request to read Three Registers Starting at 40201:
Request Response
Field Name (Hex) Field Name (Hex)
Function 03 Function 03
Starting Address Hi 9D Byte Count 0C
