Digital Weighing Indicator
SI 4100
- 37 -
8
76,800bps
9
115,200bps
DATA Transference Method selection
F32
●
0
Simplex Mode / Stream Mode
1
Duplex Mode / Command Mode
Print port selection (Under F32-01 setting, only)
F33
●
0
Same port as using for Command Mode.
1
The other port.
“Check-Sum” detection selection (Under F32-01 setting, only)
F34
●
0
Check-Sum data will not be included on transferred data.
1
Check-Sum data will be included on transferred data.
Serial Port Application Selection (Under F32-00 setting, only)
F35
●
0
DATA Transference purpose
1
Printing purpose (Serial Printer)
DATA Transference Mode selection (Under F32-00, F35-00 setting, only)
F36
●
0
Stream Mode : Weighing Data will be transferred continuously.
1
Finish Mode : When Finish Relay output, only 1 time transferred.
2
Manual Mode : When “Print” key input, 1 time transferred.
DATA Transference Format selection(Under F32-00, F35-00 setting, only)
F37
●
0
Format 1.
1
Format 2. (Format 1 + ID No.)
2
CAS Format
3
AND Format
Print Mode selection (Under F32-00, F35-01 setting, only)
F38
●
0
Manual Print : Whenever “Print” key input.
1
Auto Print : When Finish relay output, automatically print.
Transferred Weight DATA Byte selection
F40
●
0
7 Byte data Transfer
1
8 Byte data Transfer
■ Print Mode Setting (These settings will be apply to Serial and Parallel print)
Weight Unit selection
F41
●
0
kg
1
g
